FL Front Access Gel Battery

Short Description:

• Front Terminal  • Gel

The FL type front terminal battery comes with long lasting design life and front access connections for fast, easy installation and maintenance, and is ideally suitable for telecom outdoor equipment, renewable energy systems and other severe environments.

  • • Brand: CSPOWER / OEM Brand for customers Freely
  • • ISO9001/14001/18001;
  • • CE/UL/MSDS;
  • • IEC 61427/ IEC 60896-21/22;





Product Detail

Technical Data

Product Tags

> Characteristics

FL SERIES FRONT TERMINAL GEL BATTERY

  • Voltage: 12V
  • Capacity: 12V55Ah~12V200Ah
  • Designed floating service life: 12-15 years @ 25 °C/77 °F.
  • Brand: CSPOWER / OEM Brand for customers Freely

Certificates: ISO9001/14001/18001 ; CE/IEC 60896-21/22 / IEC 61427 /UL Approved

> Summary For Front Terminal Slim Battery

As a well renowned front access lead acid battery manufacturer in China, CSPOWER offers the widest selection of front access AGM batteries and GEL VRLA batteries. The gel technology has numerous superiorities over the equivalent AGM battery range, especially for telecommunication applications.
The FL type front terminal battery comes with long lasting design life and front access connections for fast, easy installation and maintenance, and is ideally suitable for telecom outdoor equipment, renewable energy systems and other severe environments.

> Features For Telecom Battery

1. This stationary battery comes with a superior gel electrolyte where sulfuric acid is evenly mixed with silica fume and acid layering does not exist.

2. The electrolyte is gel like and immobile, which enables no leakage and uniform reaction of battery plates.

3. Serving as perfect power supply equipment, the front access lead acid battery is designed with slim shape. Front access terminal connection is convenient for installation and maintenance, and space serving.

4. Radial type grid design and tight assembly technology enable prominent high rate discharge performance for our GEL VRLA battery.

5. Due to a unique design, the electrolyte volume of this battery can not reduce in use, and it requires no watering during service life.

6. Special anti-corrosion grid alloy is utilized so that the energy storage device comes with more than 12years of design life at 25degree.

7. High purity raw materials ensure super low battery self discharge.

8. Thanks to the use of gas recombination technology, our industrial battery boasts extremely high seal reaction efficiency and yields no acid mist, thus friendly and pollution-free to the environment.

9. By means of special design and high reliable sealing technology, the battery is well sealed, thus ensuring definite safety.

> Application For Front Access Battery

1. Suitable for 19inch and 23inch power cabinet.

2. Used in telecom system including exchange board, microwave station, mobile base station, data center, radio and broadcast station.

3. Great for power supply system of private network or LAN.

4. Used as signal system battery and emergency lighting system battery.

5. Perfect for EPS and UPS, Inverter system.

6. Solar and wind system


  • Previous:
  • Next:

  • CSP-MODEL

    Voltage (V)

    Capacity
    (Ah)

    Length
    (mm)

    Width
    (mm)

    Height
    (mm)

    Total Height
    (mm)

    Weight
    (kg)

    Terminal

    Bolt

    FL12-55

    12

    55/10HR

    277

    106

    223

    223

    16.5

    T2

    M6×14

    FL12-80

    12

    80/10HR

    562

    114

    188

    188

    25.5

    T3

    M6×16

    FL12-100

    12

    100/10HR

    507

    110

    223

    223

    30

    T4

    M8×18

    FL12-105/110

    12

    110/10HR

    394

    110

    286

    286

    31

    T4

    M8×18

    FL12-125

    12

    125/10HR

    552

    110

    239

    239

    38.5

    T4

    M8×18

    FL12-150

    12

    150/10HR

    551

    110

    288

    288

    44.5

    T4

    M8×18

    FL12-160

    12

    160/10HR

    551

    110

    288

    288

    45

    T4

    M8×18

    FL12-175

    12

    175/10HR

    546

    125

    316

    323.5

    54

    T5

    M8×20

    FL12-180

    12

    180/10HR

    560

    125

    316

    316

    55.5

    T5

    M8×20

    FL12-200B

    12

    200/10HR

    560

    125

    316

    316

    57

    T5

    M8×20

    FL12-200A

    12

    200/10HR

    560

    125

    316

    316

    58

    T5

    M8×20

    Products will be improved without notice, please contact sales for specification in kind prevail.
